Cement Ball Mill

Cement Mill Introduction:
High-efficiency cement mill is mainly used in grinding raw materials and final products in cement plant. And it is also suitable for grinding various ores and other materials in metallurgy, chemical, and power industry, etc. In our company,this machine has increased the productivity greatly, and the specific surface area is large, it is a new energy-saving grinding equipment, which has realized high capacity and super fine. Compared to internationally stipulated ball mill with same specifications, under the other situation of the same parameters, the output per machine hour has increased by 20%, and the power consumption per unit product has decreased by 10-15%. For open-circuit grinding, the specific surface area of cement can reach above 320㎡/kg. Besides, the performance of this machine has reached international advanced level, and it is suitable for close-circuit grinding, together with separator.

Main Technical Parameters of Cement Ball Mill:

Product size (m) Grinder Style Rotate Style Reducer Motor Power(Kw) Production
Capacity(t/h)
Weight(t)
Model Speed Ratio
φ1.83×7 Straight Edge ZD60 4.5 245 6.5-8 36
φ2.2×7.5 Circle Edge ZD70 5 380 8-10 56
φ2.2×11 Straight Centre D110 35.5 630 12-13 104.6
φ2.2×13 Straight Centre D110 35.5 630 16-18 114
φ2.4×13 Straight Centre D110 35.5 800 20-23 171.5
φ2.6×13 Straight Centre MFY100 19.5 1000 28-32 149.7
φ3×9 Circle Edge D125 41.2 1000 28-36.5 136.4
φ3×11 Circle Centre D140 42.8 1250 36-47 180
φ3.2×13 Straight Centre D140 36.5 1600 45-50 198
φ3.8×13 Straight Centre MFY250 16.5 2500 60-62 204
φ4.2×13 Straight Centre JQS3550 15.6 3530 85-87 254
